Product Description
2-Pin - Microphone & Electrical Cable Connector - Male Plug
The CMC-2M is a rugged 2-pin circular cable connector designed for microphone, communications, audio, control, and low-voltage electrical applications. Its durable metal construction and 16 mm threaded screw-lock coupling provide a secure connection that helps resist vibration and accidental disconnection.
The CMC-2M is well suited for Ham Radio and CB Radio microphone applications, as well as electronic equipment, control systems, instrumentation, and other applications requiring a reliable two-conductor connection.
Key Features
- 2-pin circular cable connector
- GX16-2 style / 16 mm threaded connector
- Male cable connector
- Ideal for Ham Radio and CB Radio microphone applications
- Suitable for low-voltage power, control, and signal connections
- Threaded screw-lock coupling provides a secure connection
- Solder-type terminals for reliable wire termination
- Rugged metal construction
- Nickel/chrome-plated finish
- Knurled coupling ring for easy hand tightening
- Designed for secure mating with compatible 2-pin panel connectors
- Suitable for replacement, repair, and custom cable assemblies
Common Applications
Two-Way Radio Microphones
The CMC-2M is suitable for microphone and accessory connections on amateur radio and CB radio equipment where a rugged, threaded two-pin connector is desired.
Communications Equipment
Ideal for radio accessories, communication equipment, control boxes, and electronic equipment requiring a secure 2-conductor connection.
Low-Voltage Electrical Connections
Suitable for low-voltage power, control, and signal wiring where a mechanically secure removable connection is required.
Electronic & Industrial Equipment
Can be used with electronic equipment, instrumentation, test equipment, control panels, and custom cable assemblies.
Specifications
| Part Number | CMC-2M |
| Connector Type | 2-Pin Circular Cable Connector |
| Style | GX16-2 Style |
| Number of Pins | 2 |
| Connector Gender | Male Cable Connector |
| Application | Ham Radio, CB Radio, Microphone, Audio & Low-Voltage Electrical |
| Coupling | Threaded Screw-Lock |
| Nominal Thread Size | 16 mm |
| Termination | Solder |
| Body Material | Metal / Zinc Alloy |
| Finish | Nickel/Chrome Plated |
| Coupling Ring | Knurled Metal |
| Mounting | Cable / Inline |
| Mating Connector | Compatible GX16-2 / 2-Pin Panel Connector |
Installation
- Prepare the cable and strip the conductors to the appropriate length.
- Disassemble the connector housing and cable clamp.
- Feed the cable through the rear of the connector.
- Solder the two conductors to the appropriate connector terminals.
- Secure the cable using the built-in cable clamp.
- Reassemble the connector housing.
- Mate the connector with the corresponding 2-pin panel connector and tighten the threaded coupling ring.
Product Highlights
- 2-pin circular cable connector
- GX16-2 style
- 16 mm threaded locking system
- Rugged metal construction
- Nickel/chrome-plated finish
- Knurled grip for easy connection
- Solder termination
- Suitable for Ham & CB radio applications
- Ideal for microphone and communication equipment
- Suitable for low-voltage control and signal applications
- Designed for secure, vibration-resistant connections
- Excellent for replacement connectors and custom cable assemblies
