Product Description
Type N Male Coaxial Connector
The Type N Male Plug Coaxial Connector is a robust, threaded RF connector designed to provide a secure, weather-resistant connection for 50-ohm coaxial cable systems. Featuring a center contact pin and a 5/8"-24 threaded coupling, the connector provides reliable mechanical retention and stable RF performance in demanding applications.
Fits RG-8, RG-11, RG-83, RG-213, RG-214, RG-393, LMR-400, and Belden 9913 coaxial cables.
Key Features
- Type N Male Configuration – Features a protruding solid center pin surrounded by a cylindrical metal outer conductor.
- 5/8-24 Threaded Coupling – Provides a secure, vibration-resistant connection for demanding RF applications.
- 50-Ohm Impedance – Designed primarily for standard 50-ohm RF systems
- Wide Frequency Capability – Standard Type N designs commonly support frequencies up to 11 GHz.
- Weather-Resistant Construction – Threaded, sealed designs provide excellent protection against moisture and environmental exposure, making them suitable for outdoor installations.
- Rugged Metal Construction – Silver plated machined brass alloy for strength, durability, and long-term reliability.
- Low-Loss RF Performance – Engineered to provide dependable signal transmission with excellent shielding and secure electrical contact.
- Antennas & Wireless Systems – Connecting coaxial feedlines to cellular, Wi-Fi, two-way radio, and amateur radio antennas.
Typical Applications
- Telecommunications – Used in base stations, wireless infrastructure, distributed antenna systems, and broadcast equipment.
- RF Test Equipment – Provides reliable connections for spectrum analyzers, signal generators, network analyzers, and other RF test equipment.
- Military & Industrial Systems – Suitable for rugged applications where secure connections, environmental resistance, and dependable RF performance are required.
- Outdoor RF Installations – Well suited for applications requiring a durable, weather-resistant connection between equipment and coaxial cable.
Typical Applications
Connector Type: Type N Male
Impedance: 50 Ohms
Coupling: 5/8"-24 Threaded
Typical Frequency Range: DC–11 GHz
Construction: Machined Brass Alloy
Application: RF, Microwave, Wireless, Telecommunications & Test Equipment
