Product Description
SMA Double Female Bulkhead Panel Flange Connector
The ARS-G815 is a 50-ohm SMA female-to-female bulkhead connector designed to pass an RF connection through an equipment panel, enclosure, or chassis. Its compact approximately 1-inch overall length and 1/2-inch diameter make it suitable for space-constrained installations.
Constructed from gold-plated brass alloy, the connector provides a durable, corrosion-resistant connection for RF applications from DC to 6 GHz. The double-female SMA configuration connects two SMA male cables or devices and can also serve as a sacrificial adapter to reduce wear on equipment ports.
Key Specifications
- Part Number: ARS-G815
- Connector: SMA Female to SMA Female
- Impedance: 50 Ohms
- Frequency Range: DC–6 GHz
- Overall Length: Approximately 1 inch
- Overall Diameter: Approximately 1/2 inch
- Body: Gold-plated brass alloy
- Mounting: Bulkhead/feed-through
- Thread: 1/4"-36 UNS
- Configuration: Jack-to-Jack
Applications: Wi-Fi and cellular antenna systems, SDR equipment, ham radio, RF test equipment, IoT gateways, FPV systems, radio enclosures, and other RF applications requiring a panel-mounted SMA feed-through connection.
