Product Description
SMA Quick-Disconnect Male-to-Female Coaxial Adapter
The ARS-4505 'Low-Loss' SMA Quick-Disconnect Male-to-Female Coaxial Adapter is designed to provide fast, convenient RF connections without the repeated twisting and unscrewing required by standard SMA interfaces. Its push-on or slide-on quick-disconnect design allows equipment, cables, and test assemblies to be connected and disconnected quickly with minimal effort. The adapter typically combines a standard threaded SMA female (jack) interface with a quick-disconnect SMA male (plug) interface, providing a practical solution for applications requiring frequent RF connection changes.
Key Features
- Impedance: 50-Ohms
- Frequency Range: DC to 12 GHz
- Quick-Disconnect Design – Push-on/slide-on connection eliminates repetitive threading for faster RF setup and teardown.
- Locking: Locking is achieved by making a 1/4 twist to secure the connector.
- SMA Male-to-Female Configuration – Combines a standard threaded SMA female jack with a quick-disconnect SMA male plug.
- Tool-Free Operation – Enables rapid mating and un-mating without a torque wrench or other tools.
- Connector Saver Function – Can be used as a sacrificial interface to reduce wear on expensive test-equipment SMA ports.
- Reduced Thread Wear – Minimizes repeated mechanical stress on standard SMA threaded connections.
- Ideal for Repeated Testing – Particularly useful when connecting and disconnecting numerous devices during production or laboratory testing.
- Compact RF Adapter – Maintains a small form factor suitable for test fixtures, RF modules, antennas, and communication equipment.
Common Applications
- Antenna Testing: Speeds up repeated testing of Wi-Fi, cellular, IoT, and other RF antennas.
- Test & Measurement: Provides convenient connections to RF test equipment and modules.
- Connector Protection: Helps protect frequently used equipment ports from mating-cycle wear.
- Field Deployments: Allows technicians to make rapid RF connections and configuration changes.
- Production Testing: Reduces connection time when testing large quantities of RF devices.
- RF Development: Useful for prototyping, laboratory setups, and equipment requiring frequent reconfiguration.
Also Known As: SMA quick-connect adapter, SMA snap-on adapter, SMA push-on adapter, or SMA slide-on adapter.
