Product Description
ARS-G840-G – SMA Male to Female 90° Coaxial Adapter
The ARS-G840-G is a precision SMA male-to-female right-angle coaxial adapter designed to connect SMA interfaces while changing the cable or connector direction by 90 degrees. Its compact right-angle configuration is ideal for RF installations where space is limited or where excessive cable bending could place stress on the connector or coaxial cable.
The 90-degree configuration helps keep coaxial cable runs neat while reducing sharp bends and mechanical strain near the equipment connection. It can also serve as a port saver, taking the wear associated with repeated cable connections instead of placing that stress directly on an expensive RF device.
Specifications
- Configuration: Right Angle - 90°
- Impedance: 50 Ohms
- Frequency: DC to 18 GHz typical
- Connector Type: SMA Male-Female
- Body Material: Gold-plated brass alloy
- Contacts: Gold-plated beryllium copper alloy
Key Features
- SMA Male to SMA Female configuration
- 90° right-angle design for convenient cable routing
- 50-ohm impedance for standard RF applications
- DC to 18 GHz typical operating frequency range
- Gold-plated metal construction for durability and reliable RF performance
- Compact design for tight equipment layouts and enclosures
- Provides convenient gender conversion and directional change in one adapter
Applications
- Wi-Fi and wireless antenna systems
- Cellular and RF signal boosters
- Software-defined radios (SDR)
- Handheld and portable radio equipment
- RF test and measurement equipment
- Microwave systems
- RF modules and development platforms
- Applications where coaxial cables must be routed around equipment or through confined spaces
