Product Description
SMA-Male to Type N-Male Plug Coaxial Adapter Connector
The ARS-G823 is a precision SMA Male to Type N Male RF coaxial adapter designed to connect 50-Ohm RF equipment, antennas, cables, and components that use SMA Female and Type N Female interfaces. This adapter provides a convenient and reliable method of converting between the compact SMA connector and the larger, rugged Type N connector.
Constructed with a durable nickel-plated brass alloy body and a gold-plated beryllium copper alloy center contact, the ARS-G823 is designed for dependable electrical performance, mechanical durability, and repeated use in demanding RF applications. A PTFE dielectric provides insulation around the center contact while maintaining the characteristics required for high-frequency RF applications.
Key Features
- SMA Male to Type N Male coaxial adapter
- 50-Ohm impedance for standard RF applications
- Nickel-plated brass alloy body provides durability and corrosion resistance
- Gold-plated beryllium copper alloy center contact provides excellent electrical conductivity and contact reliability
- PTFE dielectric/insulator
- Precision-machined RF interfaces
- Threaded connector design provides secure mechanical connections
- Suitable for laboratory, commercial, industrial, and field applications
- Ideal for connecting equipment and cables with different RF connector interfaces
Connector Configuration
Type N Male
- Larger threaded RF connector
- Center pin contact
- Designed to mate with Type N Female connectors
SMA Male
- Compact threaded RF connector
- Center pin contact
- Designed to mate with SMA Female connectors
Electrical Specifications
| Part Number | ARS-G823 |
| Adapter Type | SMA Male to Type N Male |
| Impedance | 50 Ohms |
| Frequency Range | DC to 6 GHz typical |
| VSWR | ≤ 1.2:1 typical |
| Connector 1 | Type N Male |
| Connector 2 | SMA Male |
| Dielectric | PTFE |
Mechanical Specifications
| Specification | Details |
|---|---|
| Body Material | Brass Alloy |
| Body Finish | Nickel Plated |
| Center Contact Material | Beryllium Copper Alloy |
| Center Contact Finish | Gold Plated |
| Insulator Material | PTFE |
| Connection Type | Threaded |
| Impedance | 50 Ohms |
Typical Applications
Cellular & Signal Booster Systems
Connect outdoor antennas equipped with Type N Female connectors to cellular routers, modems, signal boosters, and other equipment using SMA Female ports.
Wireless Networking
Suitable for Wi-Fi antennas, wireless networking equipment, SDR systems, and other RF devices requiring SMA-to-Type N interface conversion.
GPS & Navigation Equipment
Useful for connecting GPS antennas, receivers, and RF components with different coaxial connector interfaces.
RF Test & Measurement
Ideal for use with spectrum analyzers, network analyzers, signal generators, RF test fixtures, and laboratory equipment.
Antenna & Coaxial Cable Systems
Provides a convenient connection between Type N and SMA coaxial cable assemblies, antennas, and RF components.
Field Service & Installation
The compact adapter is useful for technicians, RF engineers, communications installers, and field-service applications where connector conversion is required.
Product Benefits
The ARS-G823 combines a rugged nickel-plated brass alloy housing with a gold-plated beryllium copper alloy center contact to provide a dependable RF interface. Its 50-Ohm configuration makes it suitable for common cellular, wireless, antenna, and test-equipment applications while the threaded SMA and Type N interfaces provide secure connections.
At a Glance
P/N: ARS-G823
Type: SMA Male to Type N Male Adapter
Impedance: 50 Ohms
Frequency: DC–6 GHz Typical
Body: Nickel-Plated Brass Alloy
Center Contact: Gold-Plated Beryllium Copper Alloy
Insulator: PTFE
Application: RF, Cellular, Wi-Fi, GPS, SDR, Antenna & Test Equipment
