Product Description
TNC Double Female Barrel In-Series Coaxial Adapter
The ARS-G433 TNC Double Female Barrel Coaxial Adapter is a precision RF adapter designed to connect two coaxial cables or components equipped with standard TNC male connectors. This straight-through female-to-female barrel provides a secure threaded connection and is suitable for RF, wireless, communications, test equipment, antenna systems, and other coaxial applications.
The adapter features a nickel-plated brass alloy body for durability and corrosion resistance, with a gold-plated beryllium copper center contact for reliable electrical performance. Its 50-ohm impedance and operating range from DC to 11 GHz make it suitable for a wide variety of RF applications.
Key Features
- Part Number: ARS-G433
- Connector Type: TNC Female to TNC Female
- Configuration: Double Female / Straight Barrel
- Impedance: 50 Ohms
- Frequency Range: DC to 11 GHz
- Body Material: Nickel-Plated Brass Alloy
- Center Contact: Gold-Plated Beryllium Copper
- Coupling: Threaded TNC connection
- Application: RF coaxial cable and equipment interconnection
Applications
- Cable Extension: Connect two coaxial cables terminated with TNC male plugs to create a longer cable assembly.
- RF Equipment Interconnection: Connect TNC-equipped radios, antennas, test equipment, and other RF devices.
- Test & Measurement: Useful as an inline adapter for RF test setups and laboratory equipment.
- Antenna Systems: Provides a convenient female-to-female connection between TNC components.
- Port Protection: Can be used as a sacrificial adapter where repeated mating and unmating could otherwise wear an equipment connector.
Product Description
The ARS-G433 is a 50-ohm TNC female-to-female barrel adapter manufactured for reliable RF connectivity. The threaded TNC interface provides a secure mechanical connection with good resistance to vibration and accidental separation compared with bayonet-style connectors.
Its nickel-plated brass alloy construction provides a durable exterior, while the gold-plated beryllium copper contact provides a reliable conductive interface. With performance specified from DC through 11 GHz, the ARS-G433 is well suited for communications, wireless, antenna, RF test, and electronic applications.
