Product Description
3.5 mm Mono Phono Plug to SO-239 UHF Female Adapter
The ARS-G524-GP is a precision RF adapter featuring a 3.5 mm mono phono plug (TS) on one end and an SO-239 (UHF-Female) connector on the other. Designed for applications requiring a compact transition between a 3.5 mm mono plug connection and a standard UHF/SO-239 interface.
The adapter features a nickel-plated brass alloy body with a smooth, durable finish, a knurled grip for secure handling, and 5/8"-24 UNEF external threads on the SO-239 side. The SO-239 center contact is gold-plated brass alloy, while the dielectric is Delrin.
Key Features
- 3.5 mm Mono Phono Plug (TS)
- SO-239 / UHF-Female connection
- 5/8"-24 UNEF threads
- Nickel-plated brass alloy body
- Gold-plated brass alloy center contact
- Delrin dielectric
- Knurled body for improved grip
- Smooth, polished nickel-plated exterior
- Compact adapter design
- Nominal 50-ohm impedance
Specifications
| Part Number | ARS-G524-GP |
| Connector 1 | 3.5 mm Mono Phono Plug (TS) |
| Connector 2 | SO-239 (UHF-Female) |
| Thread | 5/8"-24 UNEF |
| Impedance | 50 Ohm nominal |
| Body Material | Brass Alloy, Nickel Plated |
| Center Contact | Gold-Plated Brass Alloy |
| Dielectric | Delrin |
| Overall Length | Approx. 2.07" (52.5 mm) |
| 3.5 mm Plug Diameter | Approx. 0.138" (3.5 mm) |
| SO-239 Body Diameter | Approx. 0.625" (15.9 mm) |
| Knurled Section Diameter | Approx. 0.687" (17.5 mm) |
Applications
The ARS-G524-GP can be used for RF test equipment, amateur radio, communications equipment, audio/RF interface applications, prototypes, laboratory setups, and custom cable or adapter assemblies where a 3.5 mm mono plug must interface with an SO-239/UHF connection.
Note: Dimensions are nominal and provided for reference. Connector materials and plating are selected for durability and corrosion resistance. Users should verify dimensional and mechanical compatibility before installation.
