Product Description
10-Inch - SMA to UHF Coaxial Cable Pigtail
The ARS G828-CBL-10 - SMA Male to UHF Female coaxial cable pigtail is a short, flexible RF adapter cable designed to connect equipment with an SMA female antenna port to coaxial cables or antennas terminated with a UHF male (PL-259) connector. Its flexible construction provides a convenient alternative to rigid adapters while helping reduce mechanical stress on the antenna connector of portable radios.
A short flexible pigtail offers more flexibility than a solid barrel adapter and can make equipment connections easier to route and position. It is especially useful when working with portable radios, mobile antennas, legacy UHF coaxial connections, and RF test equipment.
A practical RF interconnect for bridging SMA-equipped portable equipment with standard UHF/PL-259 coaxial systems.
Key Features
- SMA Male to UHF Female connector configuration
- Flexible coaxial cable pigtail design
- Ideal for handheld and portable radio applications
- Helps reduce strain on an HT's antenna connector compared with rigid adapters
- Provides an easy connection to larger coaxial feed lines and mobile antenna systems
- Suitable for RF test equipment and SDR applications
- Useful with equipment such as portable radios, SDR dongles, and NanoVNA-style test equipment
- Compact design for field use, bench testing, and mobile installations
Common Applications
Handheld Radio to Mobile Antenna:
Provides a convenient patch connection between a handheld radio and an external antenna feed line, including vehicle-mounted antenna systems.
Connector Strain Reduction:
The flexible cable absorbs movement and positioning forces, reducing the leverage and mechanical stress that can occur when a rigid adapter is connected directly to a handheld radio.
RF Test Equipment & SDR:
Useful for connecting portable RF equipment, Software Defined Radios, antenna analyzers, and vector network analyzers to coaxial cables using standard UHF/PL-259 connections.
Specifications
- 50-Ohm
- Black Jacket
- RG-174 Coaxial Cable
- Stress Relief Heat Shrink
- SMA Male to UHF Female (SO-239)
- Cable Length: 10 Inches ( ~ 25.4 cm )
