Product Description
PL-259 UHF Male / SO-239 Female Tee Coaxial Adapter Connector
The UHF-7624 PL-259 UHF Male/Female Tee Adapter is a versatile three-way RF coaxial adapter designed to connect and route coaxial cable between one UHF male (PL-259) connection and two UHF female (SO-239) connections. Its compact T-shaped configuration makes it useful for radio installations, test equipment, antenna systems, and applications where multiple coaxial connections need to be brought together.
Key Features
- UHF Male/Female/Female Configuration – One PL-259 male plug and two SO-239 female jacks.
- Three-Way Tee Design – Provides a convenient junction for connecting multiple UHF coaxial connections.
- Nickel-Plated Brass Construction – Durable metal body provides strength and corrosion resistance.
- Gold-Plated Center Contact – Provides reliable electrical conductivity and a secure RF connection.
- 50-Ohm RF Applications – Commonly used with CB, amateur radio, and other 50-ohm coaxial systems.
- Compact Design – Easy to incorporate into existing radio and antenna installations.
- Model: UHF-7624
Connector Configuration
UHF Female / UHF Male / UHF Female
- PL-259: Male UHF connection
- SO-239: Female UHF connection
- SO-239: Female UHF connection
The male PL-259 connection mates with a standard SO-239 female socket, while the two female SO-239 ports accept standard PL-259 male plugs.
Common Applications
The UHF-7624 can be used in a variety of RF and communications applications, including:
- CB radio installations
- Amateur / ham radio stations
- Mobile radio systems
- Antenna and coaxial cable connections
- RF test and measurement setups
- Coaxial signal routing
- Equipment interconnection
- Temporary or bench-top RF configurations
Important RF Consideration
Although a UHF tee adapter can provide a convenient physical connection between multiple coaxial paths, it is not a precision 50-ohm power splitter. Using a passive tee to split or combine RF signals can introduce impedance mismatch, signal loss, reflections, and unequal power distribution. For applications requiring controlled signal splitting, a properly designed RF splitter or combiner is recommended.
Specifications
| Specification | Details |
|---|---|
| Model | UHF-7624 |
| Configuration | Female / Male / Female |
| Connectors | 2 × SO-239 Female, 1 × PL-259 Male |
| Connector Type | UHF |
| Impedance | 50 Ohms nominal |
| Body Material | Nickel-Plated Brass |
| Center Contact | Gold-Plated |
| Design | T-Shaped, 3-Way |
| Applications | CB, Ham Radio, RF & Coaxial Systems |
Product Summary
The UHF-7624 PL-259 UHF Male/Female Tee Adapter is a rugged and convenient solution for connecting three UHF coaxial interfaces in a compact T-shaped configuration. With a durable metal body, threaded UHF connections, and gold-plated center contacts, it is well suited for CB radio, amateur radio, antenna, RF testing, and general coaxial cable applications.
