Product Description
ARS-Q782 SMA Female to QMA Male Plug Coaxial Adapter
The ARS-Q782 is a superior SMA Female to QMA Male Plug coaxial adapter which provides a convenient way to connect RF equipment and cables that use different connector interfaces. It converts a standard threaded SMA female jack to a quick-connect QMA male plug, making it ideal for applications where fast installation and removal are important.
This adapter is an excellent solution when you need to transition between QMA quick-connect and SMA threaded RF connections without replacing existing cables or equipment. Its compact straight-body design and 50-ohm RF configuration make it suitable for a wide range of high-frequency applications up to 6 GHz.
Key Features
- Connector 1: SMA Female
- Connector 2: QMA Male Plug
- Impedance: 50 Ohms
- Frequency Range: DC to 6 GHz
- Configuration: Straight / in-line
- Body Material: Brass
- Plating: Nickel, Tri-Metal, or White Bronze
- Dielectric: PTFE / Teflon
- Typical VSWR: 1.15:1 to 1.18:1 maximum
- Part Number: ARS-Q782
Common Applications
The ARS-Q782 is well suited for telecommunications, RF testing, laboratory equipment, wireless communications, mobile radio systems, antennas, and RF interconnect applications. The QMA interface uses a snap-on locking mechanism for quick connection and release, while the SMA female side provides a secure threaded interface for compatible SMA male connectors.
