Product Description
BNC-Male to SMA-Female Handheld Radio Coaxial Adapter
The G829-HT-BLK is a compact, durable coaxial adapter designed to connect handheld radios equipped with BNC-female connectors to accessories or coaxial cables with SMA-male connectors. Its black chrome-plated brass body provides a professional finish and corrosion resistance, making it suitable for radio communications and other RF applications.
Specifications:
- Connector Configuration: BNC Male to SMA Female
- Impedance: 50 Ohms
- Frequency Range: DC to 4 GHz (typical)
- VSWR: ≤ 1.5:1 (typical)
- Body Material: Brass
- Body Finish: Black chrome / black plating
- Contact Material: Beryllium copper
- Contact Finish: Gold plated
- Dielectric: Delrin (SMA side); Teflon (BNC side)
- Overall Length: 28 mm (1.10 in) reference
- Body Diameter: 14.5 mm (0.57 in) reference
The G829-HT-BLK provides a convenient connection solution for handheld radios, RF accessories, and test equipment requiring a BNC-to-SMA interface. Actual performance depends on the connected equipment and operating conditions.
