Product Description
SMA Straight Male Coaxial Crimp Connector
The SMA-2518-G is a precision 50-ohm SMA straight male (plug) crimp connector designed for terminating RG-58, RG-58A, and LMR-195 coaxial cables. Featuring a captive center contact, gold-plated brass alloy body, gold-plated beryllium copper contact, and annealed copper crimp ferrule, it provides reliable RF performance for demanding communication and test applications.
- Part Number: SMA-2518
- Connector: SMA Male Plug - Straight
- Impedance: 50 Ohms
- Cable Compatibility: RG-58, RG-58A, LMR-195
- Frequency: DC–18 GHz
- Coupling Thread: 1/4"-36
- Insulator: PTFE (Teflon)
- Gasket: Silicone Rubber
- Body: Gold-Plated Brass Alloy
- Contact: Gold-Plated Beryllium Copper
- Crimp Ferrule: Annealed Copper, Gold-Plated
- Center Contact: Captive
- Voltage: 335 V Peak (RG-58 group); 250 V Peak (RG-174/RG-316 group)
- Contact Resistance: Center ≤6.0 mΩ; Body ≤2.0 mΩ
- Insulation Resistance: ≥5,000 MΩ
Ideal for wireless communications, antennas, RF test equipment, GPS/telematics, networking, and radio applications where a secure, low-loss SMA termination is required.
