Product Description
UHF Female–Female–Female SO-239 “Tee” Coaxial Adapter
The UHF-7623 is a heavy-duty UHF female-to-female-to-female “T” coaxial adapter designed to provide three 5/8"-24 UNEF threaded UHF/SO-239 connections. Its three-port configuration is useful for connecting, splitting, or routing multiple UHF/PL-259 coaxial connections in RF and radio applications.
Features
- Part Number: UHF-7623
- Configuration: UHF Female–Female–Female “T” Adapter
- Interface: Three female UHF/SO-239-style ports
- Thread: 5/8"-24 UNEF threaded coupling
- Body Material: Brass
- Body Finish: Nickel plated
- Center Contact: Brass
- Center Contact Finish: Gold
- Insulator: Delrin, white
- Frequency Range: DC–300 MHz
- Voltage Rating: 500 volts peak
- Overall Length: 40.0 mm
- Overall Height: 30.5 mm
- Impedance: Non-constant
- Temperature Range — Teflon insulation: −65°C to +165°C
- Temperature Range — Delrin insulation: −55°C to +85°C
- Mating: 5/8"-24 UNEF threaded coupling
Applications
The UHF-7623 is suitable for amateur/ham radio, CB radio, RF test equipment, antennas, coaxial cable assemblies, communications equipment, and other low-frequency RF interconnection applications where multiple UHF connections are required.
Construction
The adapter features a machined brass body with nickel plating for a durable, highly conductive and corrosion-resistant exterior. The gold-finished brass center contacts provide reliable electrical contact, while the white Delrin insulators provide mechanical support and electrical isolation.
